Lantronix TN-GLC-SX-MM-2K — TN-GLC-SX-MM Series 1000Base-SX LC SFP
$49.85$74.20
Ships from and sold by A5 IT
Free 2-3 Day ShippingArrives by Thursday, Oct 15
New, with full manufacturer warranty
Key Features
- 1000Base-SX Gigabit Ethernet network technology
- 1310nm Ext. multimode (LC) optical interface
- 2 km/1.2 mi. maximum distance
- 10.0 dB link budget
- 3.3V power input
- 0°C to 70°C operating temperature
- Lifetime warranty
The Lantronix TN-GLC-SX-MM-2K is the 1000Base-SX 1310nm Ext. multimode (LC) member of the TN-GLC-SX-MM Series. It is a Cisco compatible Gigabit SFP module for optical network and data networking applications. This SKU is listed for 2 km/1.2 mi. distance with a 10.0 dB link budget. It uses optical fiber, supports Gigabit Ethernet, and provides 1 x LC 1000Base-SX network interface. The module uses 3.3V power input with 0.66 Watts power consumption. Lantronix lists a Lifetime warranty for the series.
Ideal For
- 1000Base-SX Gigabit Ethernet links over multimode optical fiber
- Cisco compatible SFP deployments using LC fiber connections
- Optical network applications requiring 2 km/1.2 mi. maximum distance
- Data networking applications using TN-GLC-SX-MM Series SFP modules
Specifications
| Depth | 2.18” [55 mm] |
| Width | 0.52” [13 mm] |
| Height | 0.33” [8 mm] |
| Warranty | Lifetime |
| Standards | IEEE 802.3 |
| Wavelength | 1310nm |
| Link Budget | 10.0 dB |
| Power Input | 3.3V |
| Product Type | SFP (mini-GBIC) |
| TAA Compliant | Yes |
| Connector Type | LC |
| Product Series | TN-GLC-SX-MM |
| Power Consumption | 0.66 Watts |
| Network Technology | 1000Base-SX |
| Ethernet Technology | Gigabit Ethernet |
| Storage Temperature | -40°C to 85°C |
| Fiber Mode Supported | Multi-mode |
| Operating Temperature | 0°C to 70°C |
| Total Number Of Ports | 1 |
| Maximum Distance Supported | 2 km/1.2 mi. |
Frequently Asked Questions
What fiber type and connector does TN-GLC-SX-MM-2K use?▾
It uses 1000Base-SX 1310nm Ext. multimode fiber with an LC connector.
What distance does this SFP support?▾
The listed maximum distance is 2 km/1.2 mi.
Is this a Cisco compatible SFP module?▾
Yes. Lantronix describes the TN-GLC-SX-MM Series as Cisco Compatible Gigabit SFP Modules.
What warranty is listed for this series?▾
Lantronix lists a Lifetime warranty for the TN-GLC-SX-MM Series.
