Lantronix M/GE-ISW-SFP-01-PD-URX — PoE Powered Hardened Receiving Media Converter
$366.00$545.00
Ships from and sold by A5 IT
Available on backorder — ships as soon as stock arrives
Free 2-3 Day Shipping — no minimumShips as soon as stock arrives. We'll confirm the lead time before your card is charged.
New, with full manufacturer warranty
Key Features
- PoE powered hardened mini converter with 10/100/1000Base-T RJ-45 to unidirectional 100/1000Base-X open SFP slot receiving conversion
- Unidirectional data transmissions over fiber to, or from, secure networks
- Simplex communications requiring one strand of fiber cable
- Transmit-only converter pairing required for applications using this receive-only converter
- Dual speed 100/1000Mbps SFP module support
- Auto-Negotiation on the 10/100/1000 copper port
- Auto-MDI/MDIX configuration
- Unidirectional data transmissions over fiber to, or from, secure networks
The Lantronix M/GE-UxX Series M/GE-ISW-SFP-01-PD-URX is a PoE Powered Hardened Mini 10/100/1000Base-T (RJ-45) to Unidirectional 100/1000Base-X Open SFP Slot Receiving Converter. Unidirectional media converters create a physically secure one-way communication channel over fiber between a secure network and an unsecure network. They combine one-way communications with the benefits of a copper to fiber media converter. This receiving converter supports dual speed 100/1000Mbps SFP modules and simplex communications that require one strand of fiber cable. Applications require a transmit-only converter to be paired with a receive-only converter. The PD version is powered by IEEE 802.3af via the TP RJ-45 port. The hardened ISW version is specified for operation from -40°C to 75°C.
Ideal For
- One-way fiber communication between networks with different security classifications
- Transmission from a classified, high-security area to a low-security area while preventing unsecure data from reentering the classified network
- Updating a secure network with data from an external source while ensuring its critical data is unable to leave the classified area
- Copper to fiber connection for 10/100/1000Base-T networking equipment
Specifications
| MTBF | Greater than 41,680 hours (MIL‐HDBK‐217F); Greater than 114,580 hours (Bellcore7 V5.0) |
| Weight | 2 lbs. [0.9 kg] |
| Pwr LED | On = Power |
| Altitude | 0 to 10,000 ft |
| Humidity | 5% to 95% (non-condensing) |
| Warranty | Lifetime |
| Standards | IEEE 802.3; IEEE 802.3z; IEEE 802.3u; IEEE 802.3ab; IEEE 802.3af (for PD Versions Only) |
| Dimensions | 1.8″ [46 mm] x 3.3” [85 mm] x 0.85” [22 mm] |
| Fiber Port | Unidirectional 100/1000Base-X Open SFP Slot |
| Copper Port | 10/100/1000Base-T (RJ-45) |
| Power Input | IEEE 802.3af via TP RJ-45 |
| Certifications | Safety: Wall Mount Power Supply, UL Listed, cUL Listed (Canada); FCC Class A, CISPR22 / EN55022 Class A, EN55034, CE Mark |
| Converter Type | PoE Powered Hardened Mini 10/100/1000Base-T (RJ-45) to Unidirectional 100/1000Base-X Open SFP Slot Receiving Converter |
| Fx-link Act LED | On = Link, Flashing = Activity |
| Tx-link Act LED | On = Link, Flashing = Activity |
| Power Consumption | 1.8 watts without the SFP module |
| SFP+ Module Support | Dual speed 100/1000Mbps SFP modules |
| Storage Temperature | -40°C to 85°C |
| Operating Temperature | -40°C to 75°C |
Frequently Asked Questions
Does this receiving converter need a matching transmit-only converter?▾
Yes. Applications require a transmit-only converter to be paired with a receive-only converter.
What SFP modules does the converter support?▾
It supports dual speed 100/1000Mbps SFP modules and uses duplex SFP modules. On the receiving converter, only the RX port is used and the TX port is deactivated.
How is this PD version powered?▾
This PD version uses IEEE 802.3af via the TP RJ-45 port for power input.
What operating temperature range applies to this hardened ISW version?▾
For M/GE-ISW-SFP-01-xx-UxX versions, the operating range is -40°C to 75°C.
