Lantronix M/GE-ISW-SX-01 — M/GE-ISW Series Media Converter
$317.88$473.00
Ships from and sold by A5 IT
Available on backorder — ships as soon as stock arrives
Free 2-3 Day Shipping — no minimumShips as soon as stock arrives. We'll confirm the lead time before your card is charged.
New, with full manufacturer warranty
Key Features
- 10/100/1000Base-T (RJ-45) to 1000Base-SX multimode SC conversion
- 220 m/722 ft. reach on 62.5/125 um fiber and 550 m/1804 ft. reach on 50/125 um fiber
- 7.5 dB link budget
- Auto-Negotiation and Auto-MDI/MDIX on copper port
- Active Link Pass Through and Fixed Full-Duplex on Fiber
- Jumbo Frame support up to 10240Bytes
- 12 – 48 VDC or 24 – 36VAC input via 2-pin terminal block
The Lantronix M/GE-ISW-SX-01 is a hardened mini Gigabit Ethernet media converter for 10/100/1000Base-T (RJ-45) to 1000Base-SX multimode SC fiber conversion. It supports 220 m/722 ft. on 62.5/125 um fiber and 550 m/1804 ft. on 50/125 um fiber, with a 7.5 dB link budget. The M/GE-ISW Series supports Auto-Negotiation, Auto-MDI/MDIX on the copper port, Fixed Full-Duplex on Fiber, Active Link Pass Through and Jumbo Frame up to 10240Bytes. Unit and port LEDs provide quick status information. The unit accepts 12 – 48 VDC or 24 – 36VAC through a 2-pin terminal block. It includes a barrel connector pig-tail cable, DIN Rail clip and Velcro; the wall mount bracket is sold separately.
Ideal For
- Integrating 1000Base-SX multimode SC fiber into 10/100/1000Base-T RJ-45 Ethernet links
- Deploying a hardened mini media converter where the listed operating range is -40°C to +75°C
- Using Auto-MDI/MDIX on the copper port with Fixed Full-Duplex on Fiber
- Installing with the included DIN Rail clip or Velcro
Specifications
| MTBF | Greater than 41,680 hours (MIL-HDBK-217F); Greater than 114,580 hours (Bellcore7 V5.0) |
| Weight | 0.40 lbs. [0.18 kg] |
| Altitude | 0 – 10,000 ft |
| Humidity | 5% to 95% (non-condensing |
| Warranty | Lifetime |
| Data Rate | 10/100/1000Mbps |
| Standards | IEEE 802.3; IEEE 802.3u; IEEE 802.3ab; IEEE 802.3z; IEEE 802.3x |
| Dimensions | 1.8” [46 mm] x 3.3” [85 mm] x 0.85” [22 mm] |
| Link Budget | 7.5 dB |
| Power Input | 12 – 48 VDC or 24 – 36VAC |
| Certifications | FCC Class A, CISPR22/EN55022 Class A, EN55034, CE Mark |
| Fiber Distance | 62.5/125 um: 220 m/722 ft.; 50/125 um: 550 m/1804 ft |
| Max Frame Size | 10240 bytes |
| Fiber Interface | 1000Base-SX, multimode SC |
| Power Connector | 2-pin terminal block |
| Copper Interface | 10/100/1000Base-T (RJ-45) |
| Power Consumption | 1.2 Watts |
| Ingress Protection | IP20 |
| Storage Temperature | -40°C to +85°C |
| Operating Temperature | -40°C to +75°C |
Frequently Asked Questions
What copper and fiber interfaces does M/GE-ISW-SX-01 support?▾
It converts 10/100/1000Base-T (RJ-45) to 1000Base-SX, multimode SC.
What fiber distances are listed for this SKU?▾
The part row lists 220 m/722 ft. on 62.5/125 um fiber and 550 m/1804 ft. on 50/125 um fiber.
What power input does this media converter use?▾
It uses a 2-pin terminal block and accepts 12 – 48 VDC or 24 – 36VAC. External power supplies are sold separately, and a barrel connector pig-tail cable is included.
What mounting hardware is included?▾
DIN Rail clip and Velcro are included. The wall mount bracket is sold separately.
