Lantronix NTC-201 Series 4G LTE Cat 1bis Industrial IoT Routers
The NTC-201 is a new compact 4G LTE Cat 1bis industrial IoT router with one Ethernet port, built as a single globally certified SKU for connecting vending, building, access control and signage equipment anywhere.
From $151.71
Overview
About the Lantronix NTC-201 Series
The NTC-201 (also written NTC201) gives remote equipment a managed cellular uplink without a different router model for every region. One part number, NTC-201-01-01, covers 21 LTE bands from B1 to B66 and carries FCC, ISED, CE, RCM, PTCRB, AT&T and Verizon certifications. LTE Cat 1bis on 3GPP Release 13 delivers up to 10 Mbps down and 5 Mbps up, matched to telemetry and transaction traffic. Lantronix states that the supply chain is NDAA-compliant.
Hardware is sized for cabinets and enclosures: a 105 x 88 x 35 mm IP40 housing with DIN-rail and multi-orientation wall-mount brackets, -30°C to +70°C operation and 8 to 40 VDC input on a terminal block. A single SMA connector takes the included antenna, and an optional soldered MFF2 SIM avoids vibration failures. Routing features include static routes, port forwarding, VRRP, DHCP options and a DoS firewall, with IPsec for up to 5 tunnels, GRE and OpenVPN.
A Linux SDK runs custom ANSI C, shell or Lua applications on the 1 GHz ARM Cortex-A8 processor with 256 MB RAM and 512 MB flash, so data can be processed at the source without a separate industrial computer. Fleets are managed through Percepxion with zero-touch provisioning, plus TR-069, LWM2M, SNMP v3, HTTPS web UI, SSH CLI and SMS commands. Lantronix positions its OTA update path as CRA-ready.
Key capabilities
- One SKU worldwide
- NTC-201-01-01 supports 21 LTE bands and carries FCC, ISED, CE, RCM, PTCRB, AT&T and Verizon certifications, standardizing deployments across regions with one antenna.
- Industrial temperature range
- The IP40 router operates from -30°C to +70°C on 8 to 40 VDC, suiting kiosk enclosures, traffic cabinets and unconditioned equipment rooms.
- Layered VPN security
- IPsec termination for up to five tunnels, OpenVPN client, server and P2P, GRE, TLS 1.3, SNMP v3 and SMS sender whitelisting protect unattended sites.
- Edge apps via SDK
- The open Linux SDK supports ANSI C, shell script and Lua, with APIs into the runtime database and a package manager in the web UI.
- Management without site visits
- Percepxion, TR-069 and LWM2M provide OTA firmware and configuration, and SMS commands can query signal strength, change APNs or reboot the router.
- Optional soldered SIM
- Alongside the 2FF Mini SIM slot, an optional ETSI MFF2 soldered SIM eliminates vibration-related SIM failures in traffic and surveillance installations.
How to choose the right NTC-201 Series part number
The NTC-201 Series has one router part number, NTC-201-01-01, which is the worldwide model for all supported LTE bands and carriers. The box includes the router, a cellular antenna, a 1 m Ethernet cable, DIN-rail bracket, horizontal DIN-rail adapter and a two-way terminal block, but no power supply. Add the PSU-0250 12 VDC 30 W wall-cube supply or the 25165 industrial DIN-rail supply. The NANT-00001-000 3 dBi LTE antenna with SMA male connector is available as a spare or replacement.
Configure & order
Find your NTC-201 Series part number
Every orderable NTC-201 Series configuration, filtered by the specs that actually differ between them. Pick what you need on the left and the matching part numbers appear here.
NTC-201-01-01
$151.71
Ships on backorder
Complete the deployment
Accessories, renewals & add-ons
Everything sold for the NTC-201 Series, organized by what it does — antennas, power— each with why you'd add it.
Antennas
1 item
4G LTE Antenna
NANT-00001-000
Single 4G LTE antenna accessory with an L-hinged SMA male connector. The NANT-00001 antenna specifications list 698–2700 MHz coverage and 4.71 dBi maximum gain.
$7.57
Ships on backorder
Power
2 items
Power Supply
PSU-0250
Wall cube power supply rated 12VDC 2.5A and 30W. It includes a 2M cable with 2 bare wires and universal AC plug EU/UK/US/SAA.
$16.57
Ships on backorder
25165
25165
Industrial DIN rail mounted power supply with 12 V DC, 2 A output. It accepts 120 V AC or 230 V AC input and provides up to 24 W output power.
$43.74
Ships on backorder
Compatibility taken from the Lantronix part-number tables for the NTC-201 Series. Don't see what you need? Request a quote — we can source the full Lantronix catalog.
Where the NTC-201 Series is used
- Always-on payment and telemetry for vending and ticketing machines
- Connecting BMS controllers, HVAC and fire alarm panels
- Cellular uplink for gates, readers and access control
- Remote management of distributed digital signage
- VPN-secured connectivity for unattended industrial equipment
NTC-201 Series datasheets & documentation
NTC-201 Series FAQ
What LTE bands does the NTC-201 support?
The NTC-201-01-01 supports LTE Cat 1bis on B1, B2, B3, B4, B5, B7, B8, B12, B13, B18, B19, B20, B25, B26, B28, B34, B38, B39, B40, B41 and B66, as a single worldwide SKU.
Is the NTC-201 certified for AT&T and Verizon?
Yes. The NTC-201-01-01 lists FCC, ISED, CE, RCM, PTCRB, AT&T and Verizon certifications. The same part number is used for deployments worldwide, so one certified device and one antenna cover North American and international sites.
What speeds does LTE Cat 1bis provide on the NTC-201?
The NTC-201 is an LTE FDD Cat 1bis, 3GPP Release 13 compliant device with downlink up to 10 Mbps and uplink up to 5 Mbps, suited to telemetry, payment and monitoring traffic.
Does the NTC-201 include a power supply?
No. The box includes the router, cellular antenna, Ethernet cable, DIN-rail bracket and adapter, and a two-way terminal block, but the PSU is not included. The router accepts 8 to 40 VDC; PSU-0250 and 25165 are listed accessories.
Can I run custom applications on the NTC-201?
Yes. The NTC-201 runs a Linux-based OS with an SDK for ANSI C, shell script and Lua applications. A built-in package manager installs apps, and APIs give full status, configuration and control access.
