Lantronix N-FXE-MT-02B — N-FXE-02B Series 100Base-FX MT-RJ PCIe NIC
$390.00
Ships from and sold by A5 IT
Available on backorder — ships as soon as stock arrives
Free 2-3 Day Shipping within the United StatesShips as soon as stock arrives. We'll confirm the lead time before your card is charged.
New, with full manufacturer warranty
Key Features
- 100Base-FX 1300nm multimode MT-RJ fiber connection with 2 km/1.2 mi. reach and 12.0 dB link budget
- PCI-Express x1 interface for PCIe systems
- Up to 200Mbps full-duplex bandwidth capacity
- IEEE 802.1Q VLAN tagging support
- PXE remote boot support with PXE Boot ROM
- Wake-on-LAN (WoL) power management
- Standard bracket attached and low-profile bracket included
- PCI-Express x1 Interface
N-FXE-02B Series is a Fiber Fast Ethernet to PCI-Express (PCIe) bus adapter that complies with IEEE 802.3u and 100Base-FX standards. This SKU uses a 100Base-FX 1300nm multimode MT-RJ interface for 2 km/1.2 mi. links with a 12.0 dB link budget. The adapter uses a PCI-Express x1 interface and is compliant with PCIe Rev 1.1. It provides up to 200Mbps full-duplex bandwidth capacity and supports IEEE 802.3x Full-Duplex Flow Control and IEEE 802.1Q VLAN tagging. For deployment, N-FXE-MT-02B supports PXE remote boot, Wake-on-LAN power management, UEFI when the PC platform BIOS supports it, and Microsoft certified drivers. A standard bracket is attached, and a low-profile bracket is included.
Ideal For
- Connecting PCI-Express systems to Fast Ethernet fiber networks
- Adding 100Base-FX 1300nm multimode MT-RJ connectivity to a server
- Supporting PXE remote boot deployments
- Using IEEE 802.1Q VLAN tagging on Fast Ethernet fiber links
Specifications
| Slot | PCIe 1.1 |
| Depth | 4.25” [108 mm] |
| Height | 2.70” [68.5 mm] |
| Weight | 1 lb. [0.45 kg] |
| Altitude | 0 – 10,000 ft |
| Humidity | 5% to 95% (non-condensing) |
| Standard | IEEE 802.3u; IEEE 802.3x; IEEE 802.1P; IEEE 802.1Q |
| Warranty | Lifetime |
| Input Power | +3.3 VDC @ 0.7A |
| Link Budget | 12.0 dB |
| Certification | EMI Standard; FCC Class B; CE Mark; RoHS |
| Link Distance | 2 km/1.2 mi. |
| Host Interface | PCI-Express x1 Interface |
| Status LED Fdx | ON = Full-duplex link |
| Network Interface | 100Base-FX 1300nm multimode (MT-RJ) |
| Power Consumption | 1.2 Watts (max) |
| Data Transfer Rate | 200 Mbit/s |
| Boot Server Support | PXE Boot ROM |
| Status LED Link Act | ON = communication link; FLASHING = activity on link |
| Storage Temperature | -15°C to 65°C |
| Operating Temperature | 0°C to 50°C |
Frequently Asked Questions
What fiber connector does N-FXE-MT-02B use?▾
N-FXE-MT-02B uses a 100Base-FX 1300nm multimode MT-RJ fiber connector.
Does this NIC support PXE remote boot?▾
Yes. The N-FXE-02B Series features PXE remote boot support and lists PXE Boot ROM under Boot Server Support.
Is a low-profile bracket included?▾
Yes. A standard bracket is attached, and a low-profile bracket is included.
Which software platforms are listed as supported?▾
Listed software support includes Windows 2003, 2008, 2012, Windows XP, Vista, Linux 2.4.x, 2.6.x, Novell Netware 5.x, 6.x, and Windows 7, 8, 10, 11.
