Lantronix C2210-1013 — Ion 10/100Base-TX to 100Base-FX Media Converter
$320.32
Ships from and sold by A5 IT
Available on backorder — ships as soon as stock arrives
Free 2-3 Day Shipping within the United StatesShips as soon as stock arrives. We'll confirm the lead time before your card is charged.
New, with full manufacturer warranty
Key Features
- 10/100Base-TX RJ-45 copper interface with 100 m/328 ft. distance
- 100Base-FX 1300nm multimode SC fiber interface with 2 km/1.2 mi. distance
- 11.0 dB link budget for the fiber connection
- Layer 2 operation with rate conversion for 10Base-T copper devices to connect to 100Base-FX fiber
- Auto-Negotiation of speed and duplex on the TP port
- Auto-MDI/MDIX on the TP port
- Link Pass Through (LPT) and Far-End-Fault (FEF) detection
The Lantronix ION C2210-1013 is a Fast Ethernet media and rate converter module for connecting 10/100Base-TX copper ports to 100Base-FX fiber ports. This configuration uses RJ-45 copper and 1300nm multimode SC fiber with a 2 km/1.2 mi. fiber distance. Operating at Layer 2, the C2210 converts copper to fiber and provides rate conversion so legacy 10Base-T copper devices can connect to 100Base-FX fiber. The module supports Auto-Negotiation of speed and duplex on the TP port, Auto-MDI/MDIX, Link Pass Through, Far-End-Fault detection, Pause, Automatic Link Restoration and field upgradeable firmware. It is manageable when installed in a managed ION chassis; manageable features require an ION Platform chassis and an ION Management Module.
Ideal For
- Integrating 100Base-FX fiber optic cabling into 10/100 copper environments
- Connecting legacy 10Base-T copper devices to 100Base-FX fiber
- Adding a Fast Ethernet media converter module to an ION Platform Chassis
- Monitoring converter status through chassis management software when used with an ION Management Module
Specifications
| MTBF | Greater than 250,000 hours (MIL-HDBK-217F); Greater than 667,500 hours (Bellcore) |
| Depth | 6.5” [165 mm] |
| Layer | Layer 2 |
| Width | 0.86” [22 mm] |
| Height | 3.4”[86 mm] |
| Weight | 1 lb. [0.45 kg] |
| Altitude | 0 – 10,000 ft |
| Humidity | 5% to 95% (non-condensing) |
| Warranty | Lifetime |
| Data Rate | 10 Mbps; 100 Mbps |
| Standards | IEEE 802.3u; IEEE 802.3x |
| Link Budget | 11.0 dB |
| Certifications | CISPR/EN55022 Class A, FCC Class A, CE Mark, EN55024 |
| Max Frame Size | 2048 bytes |
| Fiber Interface | 100Base-FX 1300nm multimode (SC) [2 km/1.2 mi.] |
| Copper Interface | 10/100Base-TX (RJ-45) [100 m/328 ft.] |
| Mac Address Table | 1K |
| Power Consumption | 2.5 Watts, 200 mA @ 13.9 VDC |
| Frame Buffer Memory | 512 Kbits |
| Operating Temperature | 0°C to 50°C |
Frequently Asked Questions
What media types does the C2210-1013 connect?▾
It converts between 10/100Base-TX RJ-45 copper and 100Base-FX 1300nm multimode SC fiber.
What distances does this SKU support?▾
The fiber interface supports 2 km/1.2 mi., and the copper interface supports 100 m/328 ft.
Is the C2210-1013 manageable?▾
Yes. The ION C2210 is manageable when installed in a managed ION chassis. Manageable features are available when used in an ION Platform chassis along with an ION Management Module.
Can this module be used in an ION Platform Chassis?▾
Yes. The C2210 Series can be used in any ION Platform Chassis.
