Lantronix M/GE-ISW-SFP-01-URX — M/GE-UxX Series Receiving Media Converter
$310.13$462.00
Ships from and sold by A5 IT
Available on backorder — ships as soon as stock arrives
Free 2-3 Day Shipping — no minimumShips as soon as stock arrives. We'll confirm the lead time before your card is charged.
New, with full manufacturer warranty
Key Features
- Receiving converter: Hardened Mini 10/100/1000Base-T (RJ-45) to unidirectional 100/1000Base-X open SFP slot
- Unidirectional data transmissions: over fiber to, or from, secure networks
- Simplex communications: requires one strand of fiber cable
- Paired deployment: applications require a transmit-only converter to be paired with a receive-only converter
- Dual speed SFP support: 100/1000Mbps SFP modules
- Copper port automation: Auto-Negotiation and Auto-MDI/MDIX on the 10/100/1000 copper port
- Status visibility: unit and port LEDs provide quick status information
- Unidirectional data transmissions over fiber to, or from, secure networks
Lantronix M/GE-ISW-SFP-01-URX is a hardened Mini Gigabit Ethernet unidirectional media converter in the M/GE-UxX Series. It converts a 10/100/1000Base-T RJ45 connection to a unidirectional 100/1000Base-X open SFP slot and is the receiving converter version. Unidirectional communication is used to safeguard information in secure environments such as government agencies and military networks. A unidirectional device, sometimes referred to as a unidirectional security gateway or a data diode, directs information only to, or from, the appropriate network. The M/GE-UxX Series combines one-way communications with copper-to-fiber media conversion. Simplex communications requires one strand of fiber cable, and applications require a transmit-only converter to be paired with a receive-only converter. This ISW version is specified for 12 – 48 VDC or 24 – 36VAC input via 2-pin terminal block and an operating range of -40°C to 75°C.
Ideal For
- One-way fiber transmission from a classified, high-security area to a low-security area
- Updating a secure network with data from an external source while preventing critical data from leaving the classified area
- Connecting fiber optic cabling to copper-based networking equipment
- Secure network designs that require a transmit-only converter paired with a receive-only converter
Specifications
| MTBF | Greater than 41,680 hours (MIL‐HDBK‐217F); Greater than 114,580 hours (Bellcore7 V5.0) |
| Depth | 3.3” [85 mm] |
| Width | 1.8″ [46 mm] |
| Height | 0.85” [22 mm] |
| Weight | 2 lbs. [0.9 kg] |
| Altitude | 0 to 10,000 ft |
| Humidity | 5% to 95% (non-condensing) |
| Standard | IEEE 802.3; IEEE 802.3z; IEEE 802.3u; IEEE 802.3ab; IEEE 802.3af (for PD Versions Only) |
| Warranty | Lifetime |
| Direction | Receiving Converter |
| Power LED | On = Power |
| Fiber Port | 100/1000Base-X Open SFP Slot |
| Copper Port | 10/100/1000Base-T (RJ-45) |
| Power Input | 12 – 48 VDC or 24 – 36VAC via 2-pin terminal block (-ISW Versions) |
| Certifications | Safety: Wall Mount Power Supply, UL Listed, cUL Listed (Canada); FCC Class A, CISPR22 / EN55022 Class A, EN55034, CE Mark |
| Converter Type | Hardened Mini 10/100/1000Base-T (RJ-45) to Unidirectional 100/1000Base-X Open SFP Slot Receiving Converter |
| Power Consumption | 1.8 watts without the SFP module |
| Storage Temperature | -40°C to 85°C |
| Operating Temperature | -40°C to 75°C |
| Fiber Link Activity LED | On = Link, Flashing = Activity |
| Copper Link Activity LED | On = Link, Flashing = Activity |
Frequently Asked Questions
Is M/GE-ISW-SFP-01-URX the transmit or receive version?▾
It is a receiving converter. The receiving converter uses the RX port on the SFP, while the TX port is deactivated.
Does this converter need to be paired with another unit?▾
Yes. Applications require a transmit-only converter to be paired with a receive-only converter.
What type of SFP module does the series support?▾
The M/GE-UxX Series supports dual speed 100/1000Mbps SFP modules. The converter uses duplex SFP modules, but this receiving version uses only the RX port.
What operating temperature range applies to this ISW version?▾
For M/GE-ISW-SFP-01-xx-UxX versions, the operating temperature is -40°C to 75°C.
