Lantronix TN-SFP-10G-D-40 — TN-SFP-10G-x-xx Series 10GBase-BX SFP
$1,007.00
Ships from and sold by A5 IT
Available on backorder — ships as soon as stock arrives
Free 2-3 Day Shipping within the United StatesShips as soon as stock arrives. We'll confirm the lead time before your card is charged.
New, with full manufacturer warranty
Key Features
- 10GBase-BX SFP+ optical transceiver with LC connector
- 1330nm TX/1270nm RX wavelength pairing for single fiber single mode links
- 40 km/24.9 mi link length with 16.0 dB link budget
- SFF-8472 Digital Diagnostic Function (DMI)
- 10G Small Form-Factor Pluggable (SFP+) MSA Compliant
- Single +3.3V power supply
- RoHS Compliant
The Lantronix TN-SFP-10G-D-40 is a Cisco Compatible 10GBase-BX SFP+ optical transceiver in the TN-SFP-10G-x-xx Series. It supports single fiber single mode LC links with 1330nm TX/1270nm RX wavelengths. This SKU is the 40 km/24.9 mi D-40 version and lists a 16.0 dB link budget. It includes SFF-8472 Digital Diagnostic Function (DMI). Applications include 10G Ethernet switches and routers and Metro Edge Switching. The series is listed as 10G Small Form-Factor Pluggable (SFP+) MSA Compliant, uses a single +3.3V power supply, and is RoHS Compliant.
Ideal For
- 10G Ethernet switches and routers
- Metro Edge Switching
- Data networking with switch, optical network, or router equipment
- Single fiber single mode LC optical links
Specifications
| Standard | IEEE 802.3z; IEEE 802.3ae |
| Warranty | Lifetime |
| Dimensions | Width: 0.52” [13 mm] x Depth: 2.18” [55 mm] x Height: 0.33” [8 mm] |
| Form Factor | Plug-in Module |
| Link Budget | 16.0 dB |
| Power Input | 3.3V |
| Rx Wavelength | 1270nm |
| TAA Compliant | TAA Compliant |
| Tx Wavelength | 1330nm |
| Certifications | IEC-60825, FDA 21, CFR 1040.10 and 1040.11 |
| Connector Type | LC |
| Network Technology | 10GBase-BX |
| Ethernet Technology | 10 Gigabit Ethernet |
| Storage Temperature | -40°C to 85°C |
| Fiber Mode Supported | Single-mode |
| Media Type Supported | Optical Fiber |
| Operating Temperature | 0°C to 70°C |
| Environmental Compliance | RoHS |
| Interfaces Ports Details | 1 x LC 10GBase-BX Network |
| Maximum Distance Supported | 40 km |
| Digital Diagnostic Function | SFF-8472 Digital Diagnostic Function (DMI) |
Frequently Asked Questions
What link distance does TN-SFP-10G-D-40 support?▾
TN-SFP-10G-D-40 supports 40 km/24.9 mi and lists a 16.0 dB link budget.
What fiber type and connector does this SFP+ use?▾
It uses a single fiber single mode LC connection.
What are the transmit and receive wavelengths?▾
This D-40 version uses 1330nm TX and 1270nm RX.
Is the TN-SFP-10G-x-xx Series MSA compliant?▾
Yes. The TN-SFP-10G-x-xx Series is listed as 10G Small Form-Factor Pluggable (SFP+) MSA Compliant.
