Lantronix TN-SFP-10G-U-40 — 40 km BiDi SFP+ Transceiver, U Endpoint
Ships from and sold by A5 IT
Available on backorder — ships as soon as stock arrives
- Maximum distance
- 40 km/24.9 mi.
- Link budget
- 16.0 dB
- Transmit wavelength
- 1270nm
- Receive wavelength
- 1330nm
- Form factor
- SFP+
- Connector
- LC
Who it's for
Is the TN-SFP-10G-U-40 the right part?
The U-40 fits network teams specifying the 1270nm transmitting end of a 40 km BiDi path. Its 16.0 dB optical budget distinguishes it from the shorter U variants while retaining their wavelength direction. With one single-mode strand and simplex LC connectivity, it supports 10G links for switching, routing, and metro edge projects where fiber allocation matters.
Ordering
Which SKU do I need?
| Part number | What’s different | Price |
|---|---|---|
| TN-SFP-10G-U-40This page | 40 km BiDi SFP+ Transceiver, U Endpoint | $1,007.00 |
| TN-SFP-10G-U-10 | Same optical direction with 10 km reach and a 5.9 dB budget. | $477.00 |
| TN-SFP-10G-D-10 | Opposite optical direction, rated for 10 km with a 5.9 dB budget. | $477.00 |
| TN-SFP-10G-U-20 | Same optical direction with 20 km reach and a 12.1 dB budget. | $689.00 |
| TN-SFP-10G-D-20 | Opposite optical direction, rated for 20 km with a 12.1 dB budget. | $689.00 |
| TN-SFP-10G-D-40 | Complementary 40 km D endpoint with TX 1330nm and RX 1270nm; also has a TAA compliance listing. | $1,007.00 |
| TN-SFP-10G-U-80 | Changes to TX 1490nm and RX 1550nm, with 80 km reach and a 23.0 dB budget. | $3,074.00 |
| TN-SFP-10G-D-80 | Uses TX 1550nm and RX 1490nm, with 80 km reach and a 23.0 dB budget. | $3,074.00 |
Match the 40 km Route to the U Direction
TN-SFP-10G-U-40 specifies 40 km reach and a 16.0 dB optical budget. Its transmitter uses 1270nm, while its receiver uses 1330nm. Those assignments make it the U endpoint for the corresponding 40 km D optic.
The distance is also listed as 24.9 miles. For the equipment schedule, record the U designation together with reach and budget so that the optical direction remains clear during ordering and installation.
Conserve Fiber with a Simplex Connection
Bidirectional 10GBase-BX traffic shares a single-mode strand, with different wavelengths assigned to outgoing and incoming light. The fiber termination is simplex LC. This architecture uses fewer strands than a duplex connection between the network devices.
The equipment interface is SFP+, and the family follows the MSA. Cisco compatibility is listed for the series. Ethernet switches, routers, and metro edge systems are the documented application categories for these 10G modules.
Carry the Support Details into the Build Record
Compatible hosts can use SFF-8472 diagnostics to monitor the optics. The module takes 3.3V and is specified for operation from 0°C through 70°C. Storage limits are -40°C and 85°C.
Its dimensions are 13 mm wide, 55 mm deep, and 8 mm high. RoHS compliance, laser safety certifications, and a lifetime warranty are listed. Retain the series datasheet and 10G SFPs User Guide Rev E as references for the selected optical configuration.
Choose this part if…
- Choose this part if the U endpoint must support a 40 km route specification.
- Pick this SKU when the required optical budget is 16.0 dB.
- Choose this part if transmission must be at 1270nm and reception at 1330nm.
- Pick this SKU when one single-mode strand connects simplex LC interfaces.
- Choose this part if the host requires an SFP+ module with SFF-8472 diagnostics.
Technical data
TN-SFP-10G-U-40 specifications
Ethernet Connection
| Network technology | 10GBase-BX |
|---|---|
| Ethernet technology | 10 Gigabit Ethernet |
| Data rate | 10 Gbps |
| Media | Fiber |
| Fiber mode | Single-mode |
| Fiber count | single fiber |
| Connector | LC |
| Connector form | Simplex |
Optical Route
| Maximum distance | 40 km/24.9 mi. |
|---|---|
| Reach class | Long reach (20–40 km) |
| Link budget | 16.0 dB |
| Transmit wavelength | 1270nm |
| Receive wavelength | 1330nm |
| Output wavelength tolerance | -5.5nm < λc < +7.5nm |
Host Compatibility and DMI
| Compatibility | Cisco Compatible |
|---|---|
| MSA compliance | MSA Compliant |
| Digital diagnostics | SFF-8472 Digital Diagnostic Function (DMI) |
| Diagnostic support | DDM / DMI supported |
Electrical and Thermal
| Power input | 3.3V |
|---|---|
| Supply configuration | Single +3.3V |
| Operating temperature | 0°C to 70°C |
| Storage temperature | -40°C to 85°C |
| Temperature class | Commercial (0 °C and warmer) |
Physical Specifications
| Form factor | SFP+ |
|---|---|
| Width | 0.52” [13 mm] |
| Depth | 2.18” [55 mm] |
| Height | 0.33” [8 mm] |
Standards and Compliance
| IEEE standards | IEEE 802.3z; IEEE 802.3; IEEE 802.3ae |
|---|---|
| Certifications | IEC-60825, FDA 21, CFR 1040.10 and 1040.11 |
| Environmental compliance | RoHS |
Ordering
| Warranty | Lifetime |
|---|---|
| UPC | 648177038190 |
Questions
TN-SFP-10G-U-40 FAQ
Which remote optic completes the 40 km U/D pair?
TN-SFP-10G-D-40 is the matching D model, with a 1330nm transmitter and a 1270nm receiver. Its optical budget is also 16.0 dB.
What changes when selecting U-80 instead of U-40?
U-80 specifies 80 km reach and a 23.0 dB budget. It also changes the wavelength assignment to transmission at 1490nm and reception at 1550nm.
What electrical input is needed for the U-40?
The module requires a single 3.3V supply.
Which warranty and handling reference are available?
A lifetime warranty is listed. The documentation includes the 10G SFPs User Guide Rev E and the series datasheet.
