Lantronix TN-SFP-10G-U-20 — TN-SFP-10G-x-xx Series 10GBase-BX SFP 20 km
$462.49$689.00
Ships from and sold by A5 IT
Available on backorder — ships as soon as stock arrives
Free 2-3 Day Shipping — no minimumShips as soon as stock arrives. We'll confirm the lead time before your card is charged.
New, with full manufacturer warranty
Key Features
- 10GBase-BX SFP+ optical transceiver with LC connector
- 1270nm TX/1330nm RX single fiber single-mode operation
- 20 km/12.4 mi. maximum link length with 12.1 dB link budget
- SFF-8472 Digital Diagnostic Function (DMI)
- 10G Small Form-Factor Pluggable (SFP+) MSA compliance
- Single +3.3V power supply
- 0°C to 70°C operating temperature range
Lantronix TN-SFP-10G-U-20 is a Cisco compatible 10GBase-BX SFP+ optical transceiver in the TN-SFP-10G-x-xx Series. It uses an LC connector and supports SFF-8472 Digital Diagnostic Function (DMI). This SKU is the 1270nm TX/1330nm RX single fiber single-mode option. The Lantronix part row lists a 20 km/12.4 mi. link length and a 12.1 dB link budget. The series is specified for 10G Ethernet switches and routers, metro edge switching, optical networks and data networking. It uses 3.3V power input and operates from 0°C to 70°C.
Ideal For
- 10G Ethernet switches and routers
- Metro edge switching
- Data networking over optical fiber
- Optical network links using single-mode fiber
Specifications
| Depth | 2.18” [55 mm] |
| Width | 0.52” [13 mm] |
| Height | 0.33” [8 mm] |
| Warranty | Lifetime |
| Standards | IEEE 802.3z; IEEE 802.3; IEEE 802.3ae |
| Fiber Mode | Single-mode |
| Media Type | Optical Fiber |
| Form Factor | SFP+ |
| Link Budget | 12.1 dB |
| Power Input | 3.3V |
| Compatibility | MSA Compliant |
| Certifications | IEC-60825, FDA 21, CFR 1040.10 and 1040.11 |
| Connector Type | LC |
| Network Technology | 10GBase-BX |
| Receive Wavelength | 1330nm |
| Ethernet Technology | 10 Gigabit Ethernet |
| Maximum Link Length | 20 km/12.4 mi. |
| Storage Temperature | -40°C to 85°C |
| Transmit Wavelength | 1270nm |
| Operating Temperature | 0°C to 70°C |
| Environmental Compliance | RoHS |
| Digital Diagnostic Function | SFF-8472 Digital Diagnostic Function (DMI) |
Frequently Asked Questions
Is TN-SFP-10G-U-20 Cisco compatible?▾
The Lantronix page describes the TN-SFP-10G-x-xx Series as Cisco Compatible 10GBase SFP+ Modules.
What wavelength direction does this transceiver use?▾
This SKU is listed as 1270nm TX/1330nm RX for single fiber single mode operation with an LC connector.
What link distance does TN-SFP-10G-U-20 support?▾
The Lantronix part row lists 20 km/12.4 mi. with a 12.1 dB link budget.
Does this SFP+ transceiver include DMI?▾
Yes. The series features list SFF-8472 Digital Diagnostic Function (DMI).
